Certification project: 3c certification for audio and video equipment
How to apply for the 3C certification of audio and video equipment, and what are the standards? I believe everyone is familiar with audio and video. Video equipment refers to equipment such as speakers, earphones, microphones, and speakers, which are commonly referred to as external amplifiers and microphones. In computer audio equipment, it refers to sound cards, which can produce sound, such as MP3 players, CD players, radios, etc. Some audio equipment that cannot be heard by people's ears should also be considered audio equipment. I have encountered this in my daily life, and it is also within the mandatory scope of CCC certification for domestic sales, so I need to obtain CCC certification.
General testing items for 3C certification of audio and video products:
Marking and Instructions for Use
Structural requirements for preventing electric shock
Contact current and protection against electric shock under normal working conditions
Insulation requirements: electrical strength
Electrical clearances and creepage distances
Temperature rise and softening point under different combination conditions
Fault setting test related temperature test anti electric shock inspection related temperature test anti electric shock inspection
component
Mechanical strength drop vibration
Grounding continuity test for conductor connection terminals
Power cord tension test
Electrical connections and mechanical fixation
Stability and mechanical hazards
fireproof
Disturbance voltage injected into the power supply
harmonic current
Disturbance power
3c authentication process for video devices
1. Prepare application documents and submit them to the CQC testing agency of the Chinese authorities;
2. Accept applications from government agencies, agree to CCC factory codes and test product requirements
3. Product testing in Chinese laboratories optional: one day of pre audit time
4. Factory audit (completed in approximately one to two days): The certification body sends Chinese auditors to inspect the factory. The review usually takes two days.
5. According to the requirements of the certification body, apply for the CCC certification mark, which will be issued by the CQC organization.
6. Obtain CCC certificate
After receiving the certificate, the product can be marked with the CCC sensitive label.
How much does it cost for 3C certification of audio and video equipment
The general application fee, registration certificate fee, and factory inspection fee are all roughly the same; But the testing cost depends on what the specific product is, which testing projects are involved, and then the specific cost is determined; There is also factory tutoring fees, which are determined based on specific circumstances! If you want to know more detailed prices, please provide some relevant information such as product names, manuals, etc. before you can determine the price specifically! According to our previous case studies, the cost ranges from thousands to tens of thousands,
3c certification standard for audio and video equipment
Subclass | Product Name | According to standard number | Corresponding international standard number | Implementation Rule Number | |
0801 | Single speaker and multi speaker active speakers with a total output power below 500W (effective value) | GB13837-2012 | IEC/CISPR 13:2009 | CNCA-C08-01：2014 Implementation Rules for Compulsory Product Certification Audio and Video Equipment. pdf
CQC-C0801-2014 Implementation Rules for Compulsory Product Certification Audio and Video Equipment. pdf | |
GB17625.1-2012 | IEC 61000-3-2:2009 | ||||
GB8898-2011 | IEC 60065:2005 | ||||
0802 | Audio power amplifier | GB13837-2012 | IEC/CISPR 13:2009 | CNCA-C08-01：2014 Implementation Rules for Compulsory Product Certification Audio and Video Equipment. pdf
CQC-C0801-2014 Implementation Rules for Compulsory Product Certification Audio and Video Equipment. pdf | |
GB17625.1-2012 | IEC 61000-3-2:2009 | ||||
GB8898-2011 | IEC 60065:2005 | ||||
0804 | Radio in various radio bands | GB13837-2012 | IEC/CISPR 13:2009 | CNCA-C08-01：2014 Implementation Rules for Compulsory Product Certification Audio and Video Equipment. pdf
CQC-C0801-2014 Implementation Rules for Compulsory Product Certification Audio and Video Equipment. pdf | |
GB17625.1-2012 | IEC 61000-3-2:2009 | ||||
GB8898-2011 | IEC 60065:2005 | ||||
0805 | Audio and video recording, playback, and processing equipment in various forms of media (including various forms of media such as CDs and tapes) | GB13837-2012 | IEC/CISPR 13:2009 | CNCA-C08-01：2014 Implementation Rules for Compulsory Product Certification Audio and Video Equipment. pdf
CQC-C0801-2014 Implementation Rules for Compulsory Product Certification Audio and Video Equipment. pdf | |
GB17625.1-2012 | IEC 61000-3-2:2009 | ||||
GB8898-2011 | IEC 60065:2005 | ||||
0806 | The combination of the above five devices | GB13837-2012 | IEC/CISPR 13:2009 | CNCA-C08-01：2014 Implementation Rules for Compulsory Product Certification Audio and Video Equipment. pdf
CQC-C0801-2014 Implementation Rules for Compulsory Product Certification Audio and Video Equipment. pdf | |
GB17625.1-2012 | IEC 61000-3-2:2009 | ||||
GB8898-2011 | IEC 60065:2005 | ||||
0807 | Power adapter for audio and video equipment | GB13837-2012 | IEC/CISPR 13:2009 | CNCA-C08-01：2014 Implementation Rules for Compulsory Product Certification Audio and Video Equipment. pdf
CQC-C0801-2014 Implementation Rules for Compulsory Product Certification Audio and Video Equipment. pdf | |
GB17625.1-2012 | IEC 61000-3-2:2009 | ||||
GB8898-2011 | IEC 60065:2005 | ||||
0808 | Color TV receivers with various imaging methods | GB13837-2012 | IEC/CISPR 13:2009 | CNCA-C08-01：2014 Implementation Rules for Compulsory Product Certification Audio and Video Equipment. pdf
CQC-C0801-2014 Implementation Rules for Compulsory Product Certification Audio and Video Equipment. pdf | |
GB17625.1-2012 | IEC 61000-3-2:2009 | ||||
GB8898-2011 | IEC 60065:2005 | ||||
0809 | Monitor (excluding car TV receivers) | GB13837-2012 | IEC/CISPR 13:2009 | CNCA-C08-01：2014 Implementation Rules for Compulsory Product Certification Audio and Video Equipment. pdf
CQC-C0801-2014 Implementation Rules for Compulsory Product Certification Audio and Video Equipment. pdf | |
GB17625.1-2012 | IEC 61000-3-2:2009 | ||||
GB8898-2011 | IEC 60065:2005 | ||||
0811 | Imaging tube | GB8898-2011 | IEC 60065:2005 | CNCA-C08-01：2014 Implementation Rules for Compulsory Product Certification Audio and Video Equipment. pdf
CQC-C0801-2014 Implementation Rules for Compulsory Product Certification Audio and Video Equipment. pdf | |
0812 | Video recorder | GB13837-2012 | IEC/CISPR 13:2009 | CNCA-C08-01：2014 Implementation Rules for Compulsory Product Certification Audio and Video Equipment. pdf
CQC-C0801-2014 Implementation Rules for Compulsory Product Certification Audio and Video Equipment. pdf | |
GB17625.1-2012 | IEC 61000-3-2:2009 | ||||
GB8898-2011 | IEC 60065:2005 | ||||
0813 | Electronic keyboard | GB13837-2012 | IEC/CISPR 13:2009 | CNCA-C08-01：2014 Implementation Rules for Compulsory Product Certification Audio and Video Equipment. pdf
CQC-C0801-2014 Implementation Rules for Compulsory Product Certification Audio and Video Equipment. pdf | |
GB17625.1-2012 | IEC 61000-3-2:2009 | ||||
GB8898-2011 | IEC 60065:2005 | ||||
0814 | Antenna amplifier | GB13837-2012 | IEC/CISPR 13:2009 | CNCA-C08-01：2014 Implementation Rules for Compulsory Product Certification Audio and Video Equipment. pdf
CQC-C0801-2014 Implementation Rules for Compulsory Product Certification Audio and Video Equipment. pdf | |
GB17625.1-2012 | IEC 61000-3-2:2009 | ||||
GB8898-2011 | IEC 60065:2005 | ||||
The above is an introduction to the standards, costs, processes, and testing items for 3C certification of audio and video equipment. We have been focusing on the testing industry for more than 10 years, providing one-stop services to quickly apply for 3C certification of audio and video equipment, with high cost-effectiveness and faster cycles.
